Stainless Steel Bellows Sealed Valve, Gasketed, PCTFE Stem Tip, 3/8 in. TSW and 1/2 in. TBW, SC-11 Cleaned.
SWAGELOK SS-6BK-TW STAINLESS STEEL BELLOWS SEALED VALVE
Manufactured By: SWAGELOK
Manufacturer Part Number: SS-6BK-TW
IMS Product Code: 1888104
Packaging: Sold Individually
Safe Product SelectionThe complete catalog contents must be reviewed to ensure that the system designer and user make a safe product selection. When selecting products, the total system design must be considered to ensure safe, trouble-free performance. Function, material compatibility, adequate ratings, proper installation, operation, and maintenance are the responsibilities of the system designer and user.
Warning: Do not mix/interchange Swagelok products or components not governed by industrial design standards, including Swagelok tube fitting end connections, with those of other manufacturers.
| Spec | Value |
|---|---|
| Body Material | 316 Stainless Steel |
| Connection 1 Size | 3/8 in. |
| Connection 1 Type | Swagelok Tube Fitting |
| Connection 2 Size | 3/8 in. |
| Connection 2 Type | Swagelok Tube Fitting |
| Cleaning Process | Special Cleaning and Packaging (SC-11) |
| Maximum Temperature °F (°C) | 200 (93) |
| Minimum Temperature °F (°C) | -20 (-28) |
| CV Maximum | 1 |
| Handle Color | Green |
| Handle Style | Aluminum Bar |
| Stem Tip Material | PCTFE |
| Stem Type | Conical |
| Max Temperature Pressure Rating | 200°F @ 830 PSIG /93°C @ 57.1 BAR |
